TRACE™ TR-Wax GC Columns (Thermo Scientific™)

Analyze a wide range of polar compounds with the Thermo ScientificTM TRACETM TR-Wax GC Column. A polyethylene-glycol-based phase ideal for the analysis of all polar compounds, it is highly cross-linked and fully deactivated to provide excellent peak shape even with short chain alcohols.

Key Features

Engineered for Superior Performance

Polar phase, polyethylene glycol
Highly cross-linked and fully deactivated
Solvent washable

Applications:

Esters
Alcohols
Ketones
Glycols
Aromatic isomers

Excellent Quality and Reproducibility:
Recommended Use:

Low-bleed even at elevated temperatures
Outstanding robustness for difficult separations
Reliable and reproducible performance

Aldehydes
Essential Oils

Alternative Uses:

Acids
Alcohols
Alcohols in beverages
Alditol acetates (sugars)
Amines–Aliphatic
Amines–Aromatic
Herbicides
Ketones
Nitroaromatics
Phenols
Volatiles

Similar To:

DB-Wax
BP20
Rtx™-Wax
Stabilwax™
HP20M
HP-Wax
HP-INNOWax
SUPELCOWAX™ 10
AT™-Wax
Nukol™
CP Wax52CB
SUPEROX II
Carbowax™
PE-WAX
ZBWAX

Order Codes

Code	Description
260W309P	Catalog Number: 260W309P Unit Size: Each Diameter (Metric): 0.32 mm Length (Metric): 60 m Film Thickness: 1 μm
260W131P	Catalog Number: 260W131P Unit Size: Each Diameter (Metric): 0.32 mm Length (Metric): 15 m Film Thickness: 0.25 μm
260W142P	Catalog Number: 260W142P Unit Size: Each Diameter (Metric): 0.25 mm Length (Metric): 30 m Film Thickness: 0.25 μm
260W143P	Catalog Number: 260W143P Unit Size: Each Diameter (Metric): 0.32 mm Length (Metric): 30 m Film Thickness: 0.25 μm
260W154P	Catalog Number: 260W154P Unit Size: Each Diameter (Metric): 0.25 mm Length (Metric): 60 m Film Thickness: 0.25 μm
260W155P	Catalog Number: 260W155P Unit Size: Each Diameter (Metric): 0.32 mm Length (Metric): 60 m Film Thickness: 0.25 μm
260W223P	Catalog Number: 260W223P Unit Size: - Diameter (Metric): 0.25 mm Length (Metric): 30 m Film Thickness: 0.5 μm
260W224P	Catalog Number: 260W224P Unit Size: Each Diameter (Metric): 0.32 mm Length (Metric): 30 m Film Thickness: 0.5 μm
260W225P	Catalog Number: 260W225P Unit Size: Each Diameter (Metric): 0.53 mm Length (Metric): 30 m Film Thickness: 0.5 μm
260W286P	Catalog Number: 260W286P Unit Size: Each Diameter (Metric): 0.53 mm Length (Metric): 15 m Film Thickness: 1 μm
260W296P	Catalog Number: 260W296P Unit Size: Each Diameter (Metric): 0.25 mm Length (Metric): 30 m Film Thickness: 1 μm
260W297P	Catalog Number: 260W297P Unit Size: - Diameter (Metric): 0.32 mm Length (Metric): 30 m Film Thickness: 1 μm
260W298P	Catalog Number: 260W298P Unit Size: Each Diameter (Metric): 0.53 mm Length (Metric): 30 m Film Thickness: 1 μm
