CryoPlus™ Storage Systems (Thermo Scientific™)

Key Features

Key Features

• 16 preset audible and visual alarm combinations provide maximum product protection
• Automatic defogger incorporated into the manual fill index to improve visibility during retrieval
• Liquid level sensor and fill port within vacuum space, for maximum storage and sensor protection
• Front-mounted key lock and rear-mounted recessed power switch; control panel can also be locked
• Temperature sleeve (included) provides colder temperatures and efficient vapor phase operation

Microprocessor Control

• Precise liquid level control with over 16 parameters; with autofill system
• Control panel mounted on top for convenient access and easy touchpad programming
• Digital temperature display sensor located under the lid; this indicates the highest temperature reading inside the tank
• 24 tricolor LEDs continuously display actual liquid nitrogen level and high-level/low-level setpoints
• Alarm contacts for remote monitoring of storage tank conditions

Durable Construction

• Low-profile tank with vacuum-insulated, stainless-steel chamber
• Counterbalanced lid with foamed-in-place, high density polyurethane insulation; dedicated vent; 100% clearance
• Two independent, flexible lid gaskets reduce moisture migration into the chamber
• Heavy-duty casters
• 2 mL vials based on rack configuration

Ordering Information:

Optional racks, canisters, frames and risers allow you to create an organized inventory system that provides optimum storage in liquid or vapor phase. Contact your Customer Service Representative for details.

Includes:

CryoPlus 1 has 0.5 in. 45° flare, 4 ft. (1.2 m) flexible hose. CryoPlus 2, 3, and 4 come with 0.5 in. 45° flare, 6 ft. (1.8 m) flexible hose.



• Warranty varies by country, please contact us for details

Not for use for IVD/MD in some countries.



Order Codes

Code	Description
7400	Catalog Number: 7400 Unit Size: Each Capacity (Metric): 90 L Voltage: 100/120 V
7401	Catalog Number: 7401 Unit Size: Each Capacity (Metric): 90 L Voltage: 200/230 V
7402	Catalog Number: 7402 Unit Size: Each Capacity (Metric): 200 L Voltage: 100/120 V
7403	Catalog Number: 7403 Unit Size: Each Capacity (Metric): 200 L Voltage: 200/230 V
7404	Catalog Number: 7404 Unit Size: Each Capacity (Metric): 340 L Voltage: 100/120 V
7405	Catalog Number: 7405 Unit Size: Each Capacity (Metric): 340 L Voltage: 200/230 V
7406	Catalog Number: 7406 Unit Size: Each Capacity (Metric): 552 L Voltage: 100/120 V
7407	Catalog Number: 7407 Unit Size: Each Capacity (Metric): 552 L Voltage: 200/230 V
