Revco™ RDE Series Ultra-Low Temperature Freezers (Thermo Scientific™)

Part of the Standard Performance (STP) family, Thermo Scientific™ Revco™ RDE Series ultra-low temperature freezers, powered by H-drive, feature four upright models, maximizing storage capacity from 30,000 up to 60,000 2mL vials. The RDE Series is a sustainable and reliable solution with ultimate sample security and operational savings for every lab.

Key Features

Performance

  • Powered by H-drive's hydrocarbon technology, these systems save up to  25%  in energy usage and heat rejection over conventional refrigerant ultra-low freezers1
  • Designed for daily usage, recovers cabinet temperature 20% faster after opening the door.2
  • A quiet sound output below 53 dBA, enables the freezer to come out of the hallway and into the lab
  • Meets +/-10°C validation protocols at -80°C with strong peak variation and steady-state temperature variation
  • Natural hydrocarbon refrigerants reduce system operating stresses promoting outstanding reliability and worry-free sample protection


User Friendly

  • The H-drive Information Center (HIC) combines easy to read temperature with simple capacitive touch buttons in a 5.6” display
  • Four capacities (300, 400, 500 and 600 2-inch box) to accommodate a variety of storage needs and lab footprint specifications
  • All models contain five inner doors allowing for easy sample access without exposing greater freezer content to ambient conditions
  • Improved customer convenience with new ergonomically designed handle, high contrast eye-level display, and comfortable easy-access shelf locations.
  • Compatible with most racking systems including a full range of Thermo Scientific™ racks for boxes, microplates, Thermo Scientific™ Matrix™ and Nunc CryoBank™ tubes
  • Security features including alarm settings and padlock-compatible doors


Sustainability

  • Manufactured in an award-winning, zero-waste to landfill facility
  • Lower HVAC costs as a result of less heat emission into the environment
  • Natural refrigerants and water-blown foam insulation, making the Series compliant with the U.S. Environmental Protection Agency’s Significant New Alternatives Policy (SNAP), the European Union’s F-Gas and other sustainability standards


Footnotes:

  1. Internal data comparing 11.2 kWh/day to UXF600 = 14.9 kWh/day. Data on file.
  2. Typical freezer test data based on internal testing in ambient temperature at 20°C; Typical standard validation protocol of +/-10°C.

Order Codes

Code Description
RDE60086LV Catalog Number: RDE60086LV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE30086FA Catalog Number: RDE30086FA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE30086LA Catalog Number: RDE30086LA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE30086FD Catalog Number: RDE30086FD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE30086LD Catalog Number: RDE30086LD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE30086FV Catalog Number: RDE30086FV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE30086LV Catalog Number: RDE30086LV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE40086FA Catalog Number: RDE40086FA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE40086LA Catalog Number: RDE40086LA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE40086FD Catalog Number: RDE40086FD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE40086LD Catalog Number: RDE40086LD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE40086FV Catalog Number: RDE40086FV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE40086LV Catalog Number: RDE40086LV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE50086FA Catalog Number: RDE50086FA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE50086LA Catalog Number: RDE50086LA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE50086FD Catalog Number: RDE50086FD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE50086LD Catalog Number: RDE50086LD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE50086FV Catalog Number: RDE50086FV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE50086LV Catalog Number: RDE50086LV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
RDE60086FA Catalog Number: RDE60086FA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE60086LA Catalog Number: RDE60086LA
Unit Size: Each
Voltage: 115 V
Certifications/Compliance: cULus
RDE60086FD Catalog Number: RDE60086FD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE60086LD Catalog Number: RDE60086LD
Unit Size: Each
Voltage: 208/230 V
Certifications/Compliance: cULus
RDE60086FV Catalog Number: RDE60086FV
Unit Size: Each
Voltage: 230 V
Certifications/Compliance: CE
